Description
Greenlee DVI-500 Includes
- (1) DVI-500 Digital Voltage Indicator
- (1) HP-DVI-2 2" Overhead Hook Probe
- (1) HP-DVI-6 6" Overhead Hook Probe
- (1) Carrying Case
Greenlee DVI-500 Features
- Measures voltage up to 500kv line-to-ground
- Voltage readout distinguishes between nominal and induced voltages
- Audible indication when voltage is detected
- Test Point mode available (DVI-500T model)
- Auto-shutoff and low battery indication features
- Versatile for overhead and underground applications
Greenlee DVI-500 Specifications
| Type | Digital Voltage Indicator |
| Model | DVI-500 |
| Voltage Rating | 100V - 500kV Line-to-Ground |
| Accuracy | Laboratory Calibrated to +/-3%. Typical Overhead Line in Compact Overhead Three Phase +/-10%. Other Applications Up to +/-25% |
| Display | LED Display |
| Operating Temperature | -20°F to +140°F (-29°C to +60°C) |
| Dimensions | 4.25"H x 7"W x 4.5"D (11 cm x 18 cm x 11 cm) |
| Frequency Rating | AC 60Hz (50Hz model available) |
| Included | DVI-500, HP-DVI-2 2" Overhead Hook Probe, HP-DVI-6 6" Overhead Hook Probe, HP-DVI-6 6" Overhead Hook Probe |
| Sub Brand | HDE |
